Product Specification

1. 09cupcrni-A Weathering Steel Plate:

   • Chemical Composition (wt.%):
     • Carbon (C): 0.08-0.12%
     • Copper (Cu): 0.30-0.60%
     • Chromium (Cr): 0.50-0.80%
     • Nickel (Ni): 0.30-0.60%
     • Phosphorus (P): ≤0.035%
     • Sulfur (S): ≤0.035%
   • Mechanical Properties:
     • Yield Strength (Fy): 345-480 MPa
     • Tensile Strength (Fu): 480-620 MPa
     • Elongation: ≥18%
   • Thickness Range: 4-40 mm
   • Standard Plate Sizes: 1000-3000 mm width, 2000-12000 mm length

2. 09cupcrni-B Weathering Steel Plate:

   • Chemical Composition (wt.%):
     • Carbon (C): 0.08-0.12%
     • Copper (Cu): 0.20-0.50%
     • Chromium (Cr): 0.40-0.70%
     • Nickel (Ni): 0.20-0.50%
     • Phosphorus (P): ≤0.035%
     • Sulfur (S): ≤0.035%
   • Mechanical Properties:
     • Yield Strength (Fy): 325-450 MPa
     • Tensile Strength (Fu): 450-590 MPa
     • Elongation: ≥19%
   • Thickness Range: 4-40 mm
   • Standard Plate Sizes: 1000-3000 mm width, 2000-12000 mm length

3. 05 CUPCRNI Weathering Steel Plate:

   • Chemical Composition (wt.%):
     • Carbon (C): 0.12-0.18%
     • Copper (Cu): 0.30-0.80%
     • Chromium (Cr): 0.60-1.00%
     • Nickel (Ni): 0.30-0.80%
     • Phosphorus (P): ≤0.035%
     • Sulfur (S): ≤0.035%
   • Mechanical Properties:
     • Yield Strength (Fy): 355-500 MPa
     • Tensile Strength (Fu): 490-640 MPa
     • Elongation: ≥16%
   • Thickness Range: 4-40 mm
   • Standard Plate Sizes: 1000-3000 mm width, 2000-12000 mm length

4. CORTEN-A (A633 Grade E) Weathering Steel Plate:

   • Chemical Composition (wt.%):
     • Carbon (C): ≤0.20%
     • Copper (Cu): 0.25-0.55%
     • Chromium (Cr): 0.40-1.00%
     • Nickel (Ni): ≤0.65%
     • Phosphorus (P): ≤0.04%
     • Sulfur (S): ≤0.035%
   • Mechanical Properties:
     • Yield Strength (Fy): 345-480 MPa
     • Tensile Strength (Fu): 485-635 MPa
     • Elongation: ≥18%
   • Thickness Range: 4-63 mm
   • Standard Plate Sizes: 1000-3000 mm width, 2000-12000 mm length

Product Description

Product Characteristics



1. 09cupcrni-A Weathering Steel Plate:

   • Corrosion Resistance: Excellent due to the alloying elements (Cu, Cr, Ni) that form a dense, adherent oxide layer, providing superior atmospheric corrosion resistance.
   • Atmospheric Weathering: Forms a protective oxide patina that provides long-term resistance to weathering and aesthetic appeal.
   • Weldability: Good weldability using standard welding practices.
   • Formability: Good formability and ease of fabrication.
   • Applications: Bridges, buildings, storage tanks, transportation equipment, and other structures exposed to the atmosphere.

2. 09cupcrni-B Weathering Steel Plate:

   • Corrosion Resistance: Excellent atmospheric corrosion resistance, slightly lower than 09cupcrni-A.
   • Atmospheric Weathering: Forms a protective oxide patina with a slightly darker appearance compared to 09cupcrni-A.
   • Weldability: Good weldability using standard welding practices.
   • Formability: Good formability and ease of fabrication.
   • Applications: Similar to 09cupcrni-A, but may be better suited for less aggressive environments.

3. 05 CUPCRNI Weathering Steel Plate:

   • Corrosion Resistance: Excellent atmospheric corrosion resistance, comparable to 09cupcrni-A.
   • Atmospheric Weathering: Forms a protective oxide patina with a slightly darker appearance.
   • Weldability: Good weldability using standard welding practices.
   • Formability: Good formability and ease of fabrication.
   • Applications: Bridges, buildings, storage tanks, transportation equipment, and other structures exposed to the atmosphere, especially in more aggressive environments.

4. CORTEN-A (A633 Grade E) Weathering Steel Plate:

   • Corrosion Resistance: Excellent atmospheric corrosion resistance, comparable to other weathering steel grades.
   • Atmospheric Weathering: Forms a protective oxide patina with a distinct reddish-brown appearance.
   • Weldability: Good weldability using standard welding practices.
   • Formability: Good formability and ease of fabrication.
   • Applications: Bridges, buildings, storage tanks, transportation equipment, and other structures exposed to the atmosphere, where the distinctive weathered appearance is desired.

These weathering steel grades are known for their superior resistance to atmospheric corrosion, leading to reduced maintenance and extended service life in outdoor applications. The protective oxide patina also provides an aesthetic appeal, making them a popular choice for architectural and infrastructure projects.





Application of the product



1. 09cupcrni-A Weathering Steel Plate:

   • Bridges and overpasses
   • Building facades and architectural features
   • Outdoor sculptures and monuments
   • Industrial equipment and storage tanks
   • Rail cars and transportation vehicles
   • Power generation and transmission infrastructure
   • Marine and coastal structures

2. 09cupcrni-B Weathering Steel Plate:

   • Similar applications to 09cupcrni-A, but may be better suited for less aggressive environments:
   • Outdoor furniture and street furniture
   • Signage and fencing
   • Agricultural and farming equipment
   • Mild industrial and commercial applications

3. 05 CUPCRNI Weathering Steel Plate:

   • Bridges and overpasses, especially in more aggressive environments
   • Heavy industrial equipment and machinery
   • Storage silos and tanks for corrosive materials
   • Mining and mineral processing equipment
   • Power plant and energy infrastructure
   • Transportation infrastructure (e.g., railroads, ports)

4. CORTEN-A (A633 Grade E) Weathering Steel Plate:

   • Architectural and design applications where the distinctive weathered appearance is desirable:
   • Facade cladding and exterior building elements
   • Outdoor sculpture and public art installations
   • Landscape and garden features (e.g., planters, benches)
   • Signage, fencing, and decorative structures
   • Bridge and infrastructure elements
   • Transportation vehicles and equipment

The key advantages of these weathering steel plates are their excellent atmospheric corrosion resistance, reduced maintenance requirements, and distinctive visual appeal. They are widely used in applications where the natural weathering and patina formation are valued, such as in architectural, infrastructure, and industrial settings.
