ASTM A214 ASME SA214 Welded Carbon Seamless Steel Tubes GB9948 12CrMo 15CrMo For Boiler Tube 1Cr5Mo high pressure fertil

Name: ASTM A214 ASME SA214 Welded Carbon Seamless Steel Tubes GB9948 12CrMo 15CrMo For Boiler Tube 1Cr5Mo high pressure fertil
Brand: Hongye
SKU: AH32
Rating: 4.5 (164 reviews)

Place of Origin	China
Brand Name	Hongye
Certification	ISO
Model Number	AH32
Minimum Order Quantity	25tons.We also can accept sample order.
Packaging Details	Export Packing
Delivery Time	Within 15-20 workdays after receiving deposit or L/C
Payment Terms	T/T, L/C
Supply Ability	250,000 tons/year

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details

Model NO.	1Cr5Mo High Pressure Fertiliser Pipe	Material	Seamless Steel
Width	Customized	Origin	Wuxi
Color	Silver	Certification	ROHS.ISO9001.ASTM, JIS. GB. ENASTMB
Grade	7000 Series	Brand	Hongye
Application	Transportation Tools, Door & WindGlass Wall. Heat Sink, Decorations	Technique	Extruded

Leave a Message

Product Description

Ship plate AH32 high strength hull structural steel Carbon and alloy steels used in the construction and repair of ship

Company Profile

Hongye stands out with its unique capabilities! As a leading global metal distribution company, we provide tailored product solutions to meet our clients' needs, helping them gain a competitive edge.

Founded in 2009 and headquartered in Wuxi, China, Hongye has made significant achievements in the aerospace, defense, transportation, shipbuilding, semiconductor, energy, and construction sectors over the past five years.

We offer solutions in sheets, pipes, profiles, building materials, specialty steels, stainless steels, and non-ferrous metals. Additionally, our involvement in finance and port operations strengthens our position in the metal import and export market.

With our integrated “one-stop” services that include procurement, processing, retail, and logistics, Hongye has become an industry benchmark. We excel in delivering high-quality, cost-effective products, supported by robust supply chain management to meet customer needs continuously.

Internationally, Hongye has established a solid business network in Europe, Southeast Asia, and the Middle East. Our multilingual and culturally adept trade team ensures efficient and professional service for every transaction.

Since 2010, Hongye has made notable progress in sustainability, recognized by multiple institutions. By the end of 2012, we had invested 1.22 billion RMB (200 million USD) in China's metal distribution industry, becoming a significant local investor. We aim to expand our market share through collaboration and innovation.

Looking ahead, Hongye will continue to globalize, leveraging our experience and resources to grow our international market share and aspire to be a leader in the global metal distribution industry.

Our goal is to rank among the top 10 in comprehensive strength in China's metal distribution market.

Product Specification

ASTM A214 / ASME SA214 Welded Carbon Steel Tubes:
- Material Specification: ASTM A214 / ASME SA214
- Manufacturing Process: Electric resistance welded (ERW)
- Outer Diameter: 21.3 mm to 508 mm
- Wall Thickness: 2.1 mm to 12.7 mm
- Length: Typically 6 to 12 meters
- Chemical Composition (wt.%):
  - Carbon (C): 0.12-0.22%
  - Manganese (Mn): 0.30-0.90%
  - Silicon (Si): 0.10-0.35%
  - Sulfur (S): ≤0.035%
  - Phosphorus (P): ≤0.035%
- Mechanical Properties:
  - Tensile Strength: 415-585 MPa
  - Yield Strength: 240-415 MPa
  - Elongation: ≥20%
  - Hardness: 119-179 HB
GB9948 Welded Carbon Steel Tubes:
- Material Specification: GB9948
- Manufacturing Process: Electric resistance welded (ERW)
- Outer Diameter: 21.3 mm to 508 mm
- Wall Thickness: 2.1 mm to 12.7 mm
- Length: Typically 6 to 12 meters
- Chemical Composition (wt.%):
  - Carbon (C): 0.12-0.22%
  - Manganese (Mn): 0.30-0.90%
  - Silicon (Si): 0.10-0.35%
  - Sulfur (S): ≤0.035%
  - Phosphorus (P): ≤0.035%
- Mechanical Properties:
  - Tensile Strength: 415-585 MPa
  - Yield Strength: 240-415 MPa
  - Elongation: ≥20%
  - Hardness: 119-179 HB
12CrMo and 15CrMo Alloy Steel Tubes:
- Material Specification: EN 10216-2, ASTM A213/A213M
- Manufacturing Process: Seamless
- Outer Diameter: 21.3 mm to 508 mm
- Wall Thickness: 2.1 mm to 12.7 mm
- Length: Typically 6 to 12 meters
- Chemical Composition (wt.%):
  - 12CrMo: Carbon (C) ≤0.15%, Chromium (Cr) 1.0-1.5%, Molybdenum (Mo) 0.25-0.35%
  - 15CrMo: Carbon (C) ≤0.15%, Chromium (Cr) 1.25-1.75%, Molybdenum (Mo) 0.45-0.65%
- Mechanical Properties:
  - Tensile Strength: 520-690 MPa
  - Yield Strength: 360-500 MPa
  - Elongation: ≥18%
  - Hardness: 149-201 HB
1Cr5Mo High Pressure Fertilizer Pipe:
- Material Specification: EN 10216-2, ASTM A213/A213M
- Manufacturing Process: Seamless
- Outer Diameter: 21.3 mm to 508 mm
- Wall Thickness: 2.1 mm to 12.7 mm
- Length: Typically 6 to 12 meters
- Chemical Composition (wt.%):
  - Carbon (C) ≤0.15%, Chromium (Cr) 0.8-1.2%, Molybdenum (Mo) 4.5-5.5%
- Mechanical Properties:
  - Tensile Strength: 590-760 MPa
  - Yield Strength: 410-550 MPa
  - Elongation: ≥16%
  - Hardness: 170-221 HB

The key differences among these products are the material specifications, chemical compositions, and mechanical properties, which make them suitable for various applications based on the required operating conditions, such as temperature, pressure, and corrosion resistance.

Product Description

ASTM A214 / ASME SA214 Welded Carbon Steel Tubes:
- Material Grade: ASTM A214 / ASME SA214
- Manufacturing Process: Electric resistance welded (ERW)
- Surface Finish: Smooth, mill-finished
- Dimensional Tolerances: Tight tolerances on outer diameter, wall thickness, and straightness per ASTM/ASME requirements
- Chemical Composition: Carbon steel with specified composition per ASTM A214 / ASME SA214
- Mechanical Properties:
  - Tensile Strength: 415-585 MPa
  - Yield Strength: 240-415 MPa
- Applications: Water tube boilers, superheaters, economizers, and other pressure vessel components
GB9948 Welded Carbon Steel Tubes:
- Material Grade: GB9948
- Manufacturing Process: Electric resistance welded (ERW)
- Surface Finish: Smooth, mill-finished
- Dimensional Tolerances: Tight tolerances per GB9948 standard
- Chemical Composition: Carbon steel with specified composition per GB9948
- Mechanical Properties:
  - Tensile Strength: 415-585 MPa
  - Yield Strength: 240-415 MPa
- Applications: Similar to ASTM A214 / ASME SA214, used in boiler and pressure vessel components in China
12CrMo and 15CrMo Alloy Steel Tubes:
- Material Grade: 12CrMo, 15CrMo
- Manufacturing Process: Seamless
- Surface Finish: Smooth, mill-finished
- Dimensional Tolerances: Tight tolerances per applicable standards
- Chemical Composition: Chromium-molybdenum alloy steel with specified compositions
- Mechanical Properties:
  - Tensile Strength: 520-690 MPa
  - Yield Strength: 360-500 MPa
- Applications: High-temperature and high-pressure boiler tubes, superheater tubes, and other critical pressure vessel components
1Cr5Mo High Pressure Fertilizer Pipe:
- Material Grade: 1Cr5Mo
- Manufacturing Process: Seamless
- Surface Finish: Smooth, mill-finished
- Dimensional Tolerances: Tight tolerances per applicable standards
- Chemical Composition: Chromium-molybdenum alloy steel with specified compositions
- Mechanical Properties:
  - Tensile Strength: 590-760 MPa
  - Yield Strength: 410-550 MPa
- Applications: High-pressure piping for fertilizer and chemical processing industries, as well as other critical pressure vessel and process piping applications

The key differences between these materials are the specific alloy compositions, manufacturing processes, and their suitability for different boiler, pressure vessel, and high-pressure piping applications based on factors like operating temperature, pressure, and corrosion resistance requirements.

Product Characteristics

ASTM A214 / ASME SA214 Welded Carbon Steel Tubes:
- Material: Carbon steel, ASTM/ASME specification
- Manufacturing Process: Electric resistance welded (ERW)
- Outer Diameter: Wide range, typically 21.3 mm to 508 mm
- Wall Thickness: 2.1 mm to 12.7 mm
- Length: Typically 6 to 12 meters
- Surface Finish: Smooth, mill-finished
- Dimensional Tolerances: Tight tolerances per ASTM/ASME requirements
- Chemical Composition: Carbon steel with specified C, Mn, Si, S, and P content
- Mechanical Properties:
  - Tensile Strength: 415-585 MPa
  - Yield Strength: 240-415 MPa
  - Hardness: 119-179 HB
- Typical Applications: Water tube boilers, superheaters, economizers, and other pressure vessel components
GB9948 Welded Carbon Steel Tubes:
- Material: Carbon steel, Chinese GB9948 standard
- Manufacturing Process: Electric resistance welded (ERW)
- Outer Diameter: Wide range, typically 21.3 mm to 508 mm
- Wall Thickness: 2.1 mm to 12.7 mm
- Length: Typically 6 to 12 meters
- Surface Finish: Smooth, mill-finished
- Dimensional Tolerances: Tight tolerances per GB9948 standard
- Chemical Composition: Carbon steel with specified C, Mn, Si, S, and P content
- Mechanical Properties:
  - Tensile Strength: 415-585 MPa
  - Yield Strength: 240-415 MPa
  - Hardness: 119-179 HB
- Typical Applications: Similar to ASTM A214 / ASME SA214, used in boiler and pressure vessel components in China
12CrMo and 15CrMo Alloy Steel Tubes:
- Material: Chromium-molybdenum alloy steel
- Manufacturing Process: Seamless
- Outer Diameter: Wide range, typically 21.3 mm to 508 mm
- Wall Thickness: 2.1 mm to 12.7 mm
- Length: Typically 6 to 12 meters
- Surface Finish: Smooth, mill-finished
- Dimensional Tolerances: Tight tolerances per applicable standards
- Chemical Composition: Specified Cr and Mo content, along with C, Mn, Si, S, and P
- Mechanical Properties:
  - Tensile Strength: 520-690 MPa
  - Yield Strength: 360-500 MPa
  - Hardness: 149-201 HB
- Typical Applications: High-temperature and high-pressure boiler tubes, superheater tubes, and other critical pressure vessel components
1Cr5Mo High Pressure Fertilizer Pipe:
- Material: Chromium-molybdenum alloy steel
- Manufacturing Process: Seamless
- Outer Diameter: Wide range, typically 21.3 mm to 508 mm
- Wall Thickness: 2.1 mm to 12.7 mm
- Length: Typically 6 to 12 meters
- Surface Finish: Smooth, mill-finished
- Dimensional Tolerances: Tight tolerances per applicable standards
- Chemical Composition: Specified Cr and Mo content, along with C, Mn, Si, S, and P
- Mechanical Properties:
  - Tensile Strength: 590-760 MPa
  - Yield Strength: 410-550 MPa
  - Hardness: 170-221 HB
- Typical Applications: High-pressure piping for fertilizer and chemical processing industries, as well as other critical pressure vessel and process piping applications

The key differentiating factors among these products are the material composition, manufacturing process, dimensional tolerances, and mechanical properties, which make them suitable for different boiler, pressure vessel, and high-pressure piping applications based on the specific operating requirements.

Application of the product

ASTM A214 / ASME SA214 Welded Carbon Steel Tubes:
- Water tube boilers: Used as water tubes, superheater tubes, and economizer tubes in water tube boilers for power generation and industrial applications.
- Pressure vessels: Employed in the construction of pressure vessels, such as steam drums, headers, and other pressure vessel components.
- Heat exchangers: Utilized in the construction of heat exchangers, including feed water heaters, condensers, and other heat transfer equipment.
- Process piping: Used in various process piping systems, such as steam, water, and other fluid handling applications.
GB9948 Welded Carbon Steel Tubes:
- Boiler and pressure vessel components: Similar to the applications of ASTM A214 / ASME SA214 tubes, used in the construction of boilers, pressure vessels, and related equipment in China.
- Process piping: Used in process piping systems, steam, water, and other fluid handling applications in the Chinese market.
12CrMo and 15CrMo Alloy Steel Tubes:
- High-temperature boiler tubes: Primarily used as high-temperature and high-pressure boiler tubes, superheater tubes, and other critical components in power generation and industrial boilers.
- Pressure vessel components: Employed in the fabrication of pressure vessel components, such as drums, headers, and other high-temperature and high-pressure equipment.
- Petrochemical and refinery applications: Used in piping and equipment for high-temperature and high-pressure petrochemical and refinery processes.
1Cr5Mo High Pressure Fertilizer Pipe:
- High-pressure fertilizer and chemical processing: Specifically designed for high-pressure piping applications in the fertilizer and chemical processing industries, where the increased strength and corrosion resistance of the 1Cr5Mo alloy steel is required.
- Other high-pressure process applications: Can also be used in other high-pressure process piping systems, such as those found in the petrochemical, refining, and industrial chemical sectors.

The key factors that differentiate the applications of these products are the operating conditions, such as temperature, pressure, and corrosion resistance requirements, as well as the specific industry and equipment they are used in (e.g., boilers, pressure vessels, process piping).

The ASTM A214 / ASME SA214 and GB9948 welded carbon steel tubes are generally used in more moderate operating conditions, while the 12CrMo, 15CrMo, and 1Cr5Mo alloy steel tubes are designed for more demanding high-temperature, high-pressure, and corrosive environments.
